CP PLUS CP-UNC-DA21L3C-LQ-IP 0360 CAM 2MP DOME HYBRID

2MP Dual Light Dome Camera - 30Mtr. Features 1/2.8" 2MP PS CMOS Image Sensor (0.9071 Centimeters) Max. 2MP(1920 × 1080)@1–25/30fps Instastream, H.265, H.264, H.264H, H.264B, MJPEG Support Triple stream Support Built-in Mic 3.6mm Lens (2.8mm Optional) DWDR, Day/Night (ICR), 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking IR Range of 30 Mtr., Warm Light Range of 30 Mtr., PoE, IP67 Specifications Image Sensor: 1/2.8 Effective Pixels: 1920 (H) × 1080 (V) Minimum Illumination: 0.005 lux@F1.6 (Color, 30 IRE), 0.0005 lux@F1.6 (B/W, 30 IRE), 0 lux (IR on) Angle Adjustment: Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° Shutter Speed: Auto/Manual 1/3 s–1/100,000 s RAM: 128 MB ROM: 128 MB White Balance: Auto, Natural, Street lamp, Outdoor, Manual, Regional custom Gain Control (AGC): Auto/Manual Lens Type: Fixed-focal Max. Aperture: F1.6 Lens Mount: M12 DORI Distance: 3.6mm: 52.4 m (Detect), 21.0 m (Observe), 10.5 m (Recognize), 5.2 m (Identify) 2.8mm: 45.5 m (Detect), 18.2 m (Observe), 9.1 m (Recognize), 4.6 m (Identify) Close Focus Distance: 3.6 mm: 0.9 m; 2.8 mm: 0.6 m Lens: 3.6mm Lens (2.8mm Optional) S/N Ratio: >56dB IR Number: 1 (Multi-core (IR + warm) light) IR: IR Range of 30 Mtr. Warm Light: Warm Light Range of 30 Mtr. Video Compression: Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by the sub stream) Day/Night: Auto(ICR)/Color/B/W Angle of view: 3.6 mm: H: 86°; V: 47°; D: 103° 2.8 mm: H: 101°; V: 54°; D: 119° Back Light Compensation: BLC/ HLC/ DWDR IR Control: Auto, Manual Noise Reduction: 3D NR Resolution: 2M (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) Stream Capability: Triple stream Frame Rate: Main stream: 2M P(1920 × 1080)@1–25/30fps Sub stream 1: 720p (1280 × 720), D1 (704 × 576)@1–25fps/ (704 × 480)@1–30fps, VGA (640 × 480)@1-30fps, CIF (352 × 240)@1-30fps/ (352 × 288)@1-25fps Sub stream 2: D1 (704 × 576)@1–25fps/ (704 × 480)@1–30fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps/ (352 × 288)@1-25fps Smart search: Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos Motion Detection: OFF/ON (4 areas, rectangular) Video Format: PAL/NTSC Privacy Masking: 4 areas ROI: Support (4 areas) OSD: Camera title, Date & Time Audio Compression: G.711a, G.711Mu, PCM, G.726, AAC Human body Detection: Support the classification and accurate detection of human Protocol: SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, RTMP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast SDK and API: Support Cyber Security: AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot Mirror Function: Support Audio: Built-in Mic Smart IR: Support Smart Illumination: Support Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 2M resolution and lower) Alarm Event: Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Audio detection, IMD (Intelligent motion detection), Security exception Iris Control: Fixed Ethernet: RJ-45 (10/100 Base-T) Bit Rate Control: CBR/VBR Bit Rate: H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps User/ Host: 6 (Total bandwidth: 36 M) Browser: IE, Chrome, Firefox Certificates: ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report Power Source: 12 VDC/PoE (802.3af) Power Consumption: Basic: 1.4 W (12 VDC), 2.2 W (PoE); Max.: 3.3 W (12 VDC), 4.4 W (PoE) (H.265 + intelligence on + warm light intensity) Weatherproof Standard: IP67 Operating Temperature: –40 °C to +60 °C (–40 °F to +140 °F) Operating Humidity: ≤95% (RH), non-condensing Storage Temperature: –40 °C to +60 °C (–40 °F to +140 °F) Storage Humidity: ≤95%(RH), non-condensing Casing: Metal + Plastic Dimension: 85.5 mm × 109 mm Weight: 250g

Confirm the supplied items with our team.

Warranty information will be confirmed before purchase.
